Seal Design Specialists

Experienced help on your side

You can find a lot of technical seal information online that is good enough for most low risk, static and medium pressure applications. If your application is pushing boundaries, you need experienced help on your side.

Learn more

Exceeding your expectations

Our network of specialty design and manufacturing experts will help you get from “mostly there” to fully meeting or exceeding your program statement of requirements. You will find the best seal for your application. We won’t limit you to a narrow set of choices.

Learn more

Collaboration every step of the way

No two applications are the same. We’ll collaborate with you to understand the requirements of your seal, the impact of related aspects of your application and moreover, your timeline. Getting a solution in production in a timely manner is always our focus.

Learn more
gfx grid bgstyle15m
gfx grid bgstyle16
gfx grid bgstyle15m

Early engagement drives success

Bring in our team to let you know if you’re on track. If you’ve got the best solution already, we’ll tell you as much. We’ll tell you if you’re exposed to risk by inadequate specification based on your unique use case. If you’re over specified, we’ll let you know that too, helping you earn the admiration of your procurement team.

Request a Quote quiz icon
gfx grid bgstyle1
gfx grid bgstyle1m
performance creep

"Performance Creep" Risk

We understand all the variables that can bite you from the sealing perspective. A few years after your product has been in production, the seals being installed are not performing like they used to. We call this “Performance Creep”. Advanced specification support is a set of tools we have developed to prevent Performance Creep and assure it does not derail your manufacturing program now or in the future.

test bench

Test Bench Capabilities

Wherever possible we will deploy our Test Bench capabilities to help you benchmark performance of your incumbent seal to give you a data driven performance comparison. We will actuate seals in your hardware, in modified seal glands, in your fluids, pull and compile performance data to pre-qualify our solution. So, you have higher confidence as you budget and allocate your own testing resources.

fast prototype

Fast Prototypes

We understand your timeline is always an important factor so we have fast prototyping capabilities. We have preset pricing based on seal type, size range, and compound so all you need to do is send us your digital design file and a purchase order and we’re off to the races!

The seal itself is governed by: the profile, or seal type, and the material the seal is made from.

Engagement with Darcoid equals YOUR success
