IMG_8256-1
n/a
$
block pattern

Specs

Pressure [Low]
Dynamic Service Speed [Low]
Seal Directionality [Bidirectional]
Manufacturing Method [Cutting, Extrusion, Molding],
Common modifications
Catalog Standards n/a
Customizable Yes
Comparative cost: $
grid pattern left

Special Applications

Environmental sealing, particle filter/exclusion, use as grease/lube reservoir adjacent to main seal.


More Information

In a Hurry?
Our Zund XY table cutter can generate parts within hours of receiving your solid model. For die cuts we can start running parts in days. Contact us to learn how to get parts fast.
